Product Details
＋
The e-Genius 4000 is the only keyless double lock providing the ability to lock and unlock an interconnected dead-latch and deadbolt with a single lift of the lever from inside and outside of your home. Access your home with keyless freedom and convenience using a highly responsive, 12-key illuminated touch and fingerprint resistant keypad programmable with up to 400 user user codes interchangeable with RFID keycards/stickers. Mechanical key override lock is available as an extra back-up.
- Latchbolt can always be locked so that when shutting the door, it is automatically locked
- Extended deadbolt
- Left Hand, Right Hand
- Quest Lever
- Including 2 RFID Key Cards and 2 RFID stickers
| Function | Storeroom |
| Door Thickness: | 1-3/4” |
| Backset | 2-3/8″ – 2-3/4″ adjustable |
| Lock Body | 5.5" |
| Trim |
Clutched |
| Latch bolt: | 1/2“ throw stainless steel deadlocking |
| Faceplate | 1" x 2-1/4" |
| Deadbolt Strike | 1-1/8″ x 2-3/4″ radius corners with security underplate |
| Key Override | Yes |
| Cylinder | 6 pin Schlage C keyway, standard |
| Power Supply |
4 AA Alkaline batteries - No Hard wiring |
| Battery Life |
Up to 1 year |
| Finish | 626 - US26D - Satin Chrome, 622 - US19 - Flat Black Coated |
| Handing | Left Handed, Right Handed |
| Certifications | ANSI/BHMA A156.2 -- A156.2-2011 Grade 1 certified UL/ULC -- UL 10C 3-hour rated BAA -- Meets guidelines of the Buy American Act ADA --- Meets requirements of the Americans with Disabilities Act RoHS -- Meets requirements of EU RoHS Directive 2002/95/EC |
| Manufacturer Warranty | 2-year limited for electronic 5-year limited for finish 10-year limited for mechanical |
