| Product Attribute | Attribute Value |
|---|---|
| Accuracy | 1.0% FS |
| Body Style | Rectangular |
| Connection | Screw Terminals |
| Contact Configuration | 4-20mA analog output |
| Current Rating | 10A, 20A, 50A |
| Current, Ratings | 10/20/50 A |
| Current, Switching | 20 mA |
| Enclosure Rating | Split-Core housing |
| Function | Current |
| Height | 2.25 Inch |
| Housing Type | Split Core |
| Input Voltage | 24 Vdc loop powered |
| Length | 3.3 Inch |
| Measurement Range | 50 A |
| Mounting Type | Panel Mount |
| Output | Current |
| Power, Supply | Loop 24 VDC |
| Series | |
| Supply Voltage | 24 VDC |
| Technology | Inductive |
| Type | Inductive |
| UPC Code | 786685120591 |
| Width | 1.2 Inch |
Overview
Solid-core housing models are ideal for new equipment installations where the conductor wire is ran through the fixed aperture. Split-core models are perfect for retrofit applications because the housing can be opened to fit around an existing conductor. As such, split-core current sensors are easy to install, without re-wiring and shutting down a process for long periods of time. The simplicity of installing split-core models reduces overall installation costs.
Sensors
Current sensors operate by monitoring current flow in equipment. The current magnitude is converted into a linear and proportional analog signal (4-20 mA, 0-5 V or 0-10 V). Small changes in current can be detected, avoiding costly repairs and mechanical problems before they occur. These sensors are magnetically isolated, contain internal signal conditioning, are safer to use than current transformers, do not require additional circuitry, and are completely self-contained in one compact package.
Features:
